Capture
Walk the environment while LiDAR, visual, and motion data are recorded.
Long-range handheld LiDAR scanner
Staris
Extended-reach spatial capture for outdoor and large-scale environments.
Staris pairs a non-repetitive scan pattern with long-range LiDAR, 12 MP visual capture, dual-band Wi-Fi, Bluetooth, and a 2.5-hour battery configuration.
Best fit
Where Staris is most relevant.
✓Outdoor and large-scale spatial capture
✓Long-range surveying and infrastructure documentation
✓Projects where portability and extended reach matter
70.4° × 31°Non-repetitive field of view
450 mRange at 80% reflectivity
240,000 pts/sMeasurement rate
2.5 hoursBattery life with 45 Wh battery
Specifications describe the device; they do not guarantee a project outcome. Evaluate the full workflow and expected environment.
Workflow
Capture → Preview → Process → Measure → Deliver
Preview
Use the field interface to review point-cloud coverage and task status.
Process
Run the supported post-processing workflow.
Deliver
Export the required spatial-data and model formats.
Practical relevance
Best evaluated for long-range and large-scale capture. The 450 m range applies at 80% reflectivity and should not be generalized to all surfaces or conditions.
Selection should consider range, field of view, point rate, weight, battery duration, reflectivity, environment, and downstream output requirements.
Verified specifications
Staris technical specifications
| Laser unit | Avia-LIVOX |
|---|---|
| Repeatability | 2 cm |
| Angular accuracy | 0.015° |
| Field of view | 70.4° × 31°, non-repetitive scan |
| Camera resolution | 12 MP |
| Laser class | 905 nm / Class 1 |
| Absolute accuracy | 3 cm |
| Range | 450 m at 80% reflectivity |
| Measurement rate | 240,000 points/second |
| Dimensions | 138 × 85 × 285 mm |
| Weight | 1.3 kg including battery |
| Operating temperature | -20°C to 50°C |
| Power | 15 W |
| Storage | CFexpress 128 GB standard; expandable to 1 TB |
| Wireless | 2.4 GHz / 5 GHz Wi-Fi and Bluetooth |
| Protection rating | IP54 |
| Battery life | 2.5 hours with 45 Wh battery |
Frequently asked questions
What is this model best suited for?
Best evaluated for long-range and large-scale capture. The 450 m range applies at 80% reflectivity and should not be generalized to all surfaces or conditions.
What output formats are supported?
Handheld output formats include LAS, LAZ, PLY, PCD, E57, CSV, TXT, BAG, DB, DXF, OBJ, and PLY-based 3D Gaussian outputs, depending on the workflow.
Does the listed range apply in every environment?
No. Range depends on reflectivity, atmosphere, angle, surface, and capture conditions. Any reflectivity condition shown in the specification must remain attached to the value.
Is 0.5 cm the absolute accuracy?
No. The brochure lists 3 cm product-level absolute accuracy and separately references a 0.5 cm relative-accuracy benchmark for supported workflows and conditions.
